ERKO AH 100 Hydraulic Unit | Battery Powered 630 Bar Hydraulic Pump
Description
ERKO AH 100 Battery Powered Hydraulic Pump
Product No.: AH-100
Manufacturer: ERKO
Description
Battery Powered Hydraulic Power Pack – Portable 630 Bar System
The ERKO AH 100 Hydraulic Unit is a compact, battery-powered electro-hydraulic power pack, designed for portable use with ERKO hydraulic tools and equipment.
This unit is ideal for on-site electrical work, switchgear installation, and mobile operations, where a fully portable hydraulic solution is required without reliance on mains power.
The ERKO AH 100 is designed to provide reliable hydraulic power in a portable format, allowing operators to:
- Power hydraulic punching, cutting and crimping tools
- Work in locations without mains electricity
- Quickly connect tools using the PM quick coupler system
- Maintain high performance even in demanding conditions
This makes it a perfect solution for field engineers, electrical contractors, and maintenance teams.
Key Features
✔️ Battery powered hydraulic unit (24V system)
✔️ Maximum pressure up to 630 bar
✔️ Portable and compact design (only 20kg)
✔️ Includes 2.5m hydraulic hose with PM quick coupler
✔️ Compatible with all ERKO hydraulic tools (PT coupler systems)
✔️ Ideal for on-site and remote work
✔️ Includes battery charger
Technical Specification
🔹 Power & Performance
- Max Pressure: 630 bar
- Flow Rate: 0.31 L/min at 630 bar
- Hydraulic Oil Capacity: 0.65 litres
🔹 Electrical / Battery
- Power Supply: 24V DC (battery powered)
- Battery Capacity: 9 Ah
- Charger: Included
🔹 Hydraulic System
- Quick Coupler Type: PM (high-pressure quick connect)
- Hose Length: 2.5 metres
- Compatibility: Works with ERKO tools using PT couplers
🔹 Build & Protection
- Protection Rating: IP41
🔹 Dimensions & Weight
- Dimensions (L x W x H): 415 x 315 x 220 mm
- Weight: approx. 20 kg
Includes
Battery Charger
2.5m Hose with PM quick coupler
Optional Extra
AC Adapter (230V AC / 24V DC) – allows operation from mains power instead of battery
Recommended for use with:
ERKO Hydraulic Heads & Devices
More ERKO Pumps Available Here
Specifications
| Manufacturer | ERKO |
| Model | AH 100 Battery Powered Hydraulic Pump |
| Condition | New |
| Stock Number | AH100 |
| Product No. | AH-100 |
| Manufacturer | ERKO |
| * Max Pressure | 630 bar |
| * Hydraulic Oil Capacity | 0.65 litres |
| * Power Supply | 24V DC (battery powered) |
| * Battery Capacity | 9 Ah |
| * Charger | Included |
| * Quick Coupler Type | PM (high-pressure quick connect) |
| * Hose Length | 2.5 metres |
| * Protection Rating | IP41 |
| * Weight | approx. 20 kg |
